GenSet 300A Diesel Engine Driven Welder Generator Yanmar 3TNM72 Engine (MPM 9/310 I-Y CC/CV)

Compact and durable, this engine-driven welder is designed for reliable performance and frequent handling on site. Featuring forklift pockets and a practical central lifting hook, it is easy to move and position as needed. Powered by a 3000 RPM Yanmar engine with on-board control, it is also equipped for remote control operation. The asynchronous alternator delivers high-quality welding current with a clean, distortion-free waveform for consistent results.

Shielded Metal Arc Welding (SMAW)
CV MIG (GMAW)

Built for reliable and efficient on-site operation, this engine-driven welder generator includes a range of features designed to improve control, monitoring and safety. It is equipped with arc force control, a remote control socket, and a digital controller for monitoring key generator parameters including voltage, battery voltage, frequency, running hours, oil pressure, water temperature and start-up status. Automatic engine protection shutdown helps safeguard the machine against low oil pressure, high coolant temperature, voltage faults and frequency faults. Additional features include a high alternator temperature warning light, starting battery, automatic idle function when no load is connected, emergency stop button, ELCB protection, power output protections, central lifting hook and engine oil drain pipe. For flexible power supply, it is fitted with 32A 110V and 230V single-phase sockets, plus a 16A 400V three-phase socket.

• Noise Level (LWA) 99 (74dB a 7m)
• AC Generator 50Hz Asynchronous
• Three Phase Max. Power 8kVA - 400V
• Single Phase Max. Power 4.6kVA - 230V
• Single Phase Max. Power 2.7kVA - 110V
• Power Factor
• DC Welding Electronic current regulation
• Duty Cycle @ 60% 270A - 31V
• Output Range 30A - 300A
• Open Circuit Voltage 70V
• Max Welding Rod 6mm
• Yanmar Engine 3TNM72
• Fuel Diesel
• No. Cylinders 3
• Power 19.4HP (14.4kWm)
• Displacement 904cm3
• Cooling System Water
• Starting System Electric
• Fuel Tank Capacity 30l
• Fuel Consumption @ 75% 5.1l/h
• Insulation Class H
• Ambient Temperature 40oC
• Altitude 1000m
• Degree of Protection IP23
• Dimensions (LxWxH) 1408 x 532 x 1015mm
• Dry Weight 385Kg
